Right Angle Male High Temp. 3.5mm Pitch Connector

UL/CUL

Use Group B C D

Rate Voltage [V] 300 - 300

Rated Current [A] 8 - 8

Dielectric Voltage-Withstand 1.6KV

IEC

Overvoltage Category III III II

Contamination Class 3 2 2

Rated Voltage [V] 160 160 250

Rated Current [A] 8 8 8

Impulse withstand voltage [KV] 2.5 2.5 2.5

Material

Insulation Material LCP

Flammability rating UL94V-0

Conductor Material Copper alloy

Plating of conductor surface Sn plated

Other Data

Pitch/Poles [mm]/[P] 3.5,3.81 / 2~24

Operating temperature [℃] -40~+130

Soldering temperature 285℃/ 10S

Pin dimensions [mm] 0.8*0.8

PCB Hole Diameter [mm] Ø1.4
