Pitch 5.0mm Spring Clamp Connectors PCB Terminal Block

We have a strong quality control team, and with the help of external professional resources, to control the whole process of Male Right Angle Pitch 10 16mm Connector With Flange, Spring Clamp Terminal Block 2 54mm, Double Row 5 08mm Spring Clamp Terminal Block Connector from raw material procurement to sales terminal. We sincerely thank our customers for their loyalty and trust in our company, our suppliers and all our partners for their close cooperation, as well as our team members for their dedication and hard work. Our company can realize its competitive advantage, grasp the market opportunity and choose the development strategy suitable for our company. We regard laws, regulations and rules as the standard of production and operation of the enterprise, and strictly abide by them. Our various products are produced according to national standards and industry standards, and the quality control center monitors the quality of products throughout the process.

5.0mm Connector

UL/CUL

Use Group B C D

Rate Voltage [V] 300 - 300

Rated Current [A] 12 - 10

Wire Range [AWG] 24~16

Dielectric Voltage-Withstand 1.6KV



IEC

Overvoltage Category III III II

Contamination Class 3 2 2

Rated Voltage [V] 320 320 630

Rated Current [A] 12 12 12

Impulse withstand voltage [KV] 4 4 4

Conductor cross section [mm²] 0.2~1.5



Material

Insulation Material PA66

Flammability rating UL94V-0

Conductor Material Copper alloy

Plating of conductor surface Sn plated



Other Data

Pitch/Poles [mm]/[P] 5.0 / 2~24

Stripping Length [mm] 11~12

Operating temperature [℃] -40~+105



We must improve the quality of our Pitch 5.0mm Spring Clamp Connectors PCB Terminal Block and services in order to compete better at the international level. Our company has been continuously introducing advanced production equipment, tapping high level technicians and cultivating an experienced technical team. We strive to achieve common development and win-win harmony with all stakeholders and help the country and the world achieve sustainable development.
