All Pitch Terminal Block 2.54/3.5/3.81/5.0/5.08/6.36/7.5/7.62/9.52/10.16/ ...

We promise to deliver satisfactory products to your hands with the best quality and fastest speed, and use the best solutions and the most enthusiastic and thoughtful after-sales service to solve the problems you encounter during use the Right Angle Female Male 3 81mm Pitch Connector With Screw, Vertical Spring Terminal Connector 5 0mm, Right Angle Screwless Terminal Connector 5 0mm. We integrate the gene of innovation into the blood of our own development, so that every step we move forward is beating the pulse of innovation. With years of efforts, we have established friendly and stable business relationships with worldwide customers. Our company insists on the service-oriented management policy, aims at satisfying customers' needs, and implements the integration of production and sales. Our company has been adhering to the business philosophy of 'quality for survival, reputation for development', always regard customer demand and satisfaction as the core, dedicated to create quality products for the majority of new and old customers.

UL/CUL

Use Group B C D

Rate Voltage [V] 600 600 600

Rated Current [A] 65 65 5

Wire Range [AWG] 20~6

Dielectric Voltage-Withstand 2.2KV



IEC

Overvoltage Category III III II

Contamination Class 3 2 2

Rated Voltage [V] 630 1000 1000

Rated Current [A] 76 76 76

Impulse withstand voltage [KV] 8 8 8

Conductor cross section [mm²] 2.5~16



Material

Insulation Material PA66

Flammability rating UL94V-0

Conductor Material Copper alloy

Plating of conductor surface Sn plated



Other Data

Pitch/Poles [mm]/[P] 10.16 / 2~14

Stripping Length [mm] 10

Screw/Torque(Max)[N.m] M4 / 1.2

Operating temperature [℃] -40~+105

Soldering temperature 250℃/ 5S

Pin dimensions [mm] 0.9*1.0

PCB Hole Diameter [mm] Ø1.6



All All Pitch Terminal Block 2.54/3.5/3.81/5.0/5.08/6.36/7.5/7.62/9.52/10.16/ ... sold by the company are produced in strict accordance with quality management standards and enjoy a high reputation among users. We always insist on sharing technological progress with customers and sharing a bright future with customers! The company warmly welcomes friends from all walks of life to come to the company or call to discuss business, and work together to create brilliant.
