128V-5.0mm-04p Black Screw Clamp Wiring Types Pluggable Terminal Block

With the development theme of innovation, hard work and integrity, we are striving to become a well-known enterprise of 2 5mm Pitch Screwless Terminal Block, Euro PCB Screw Terminal Block 7 62mm, 45 Degree 5 08mm Screwless Terminal Block. We adhere to the business philosophy of standardized management, insisting on integrity, pursuing excellence and pragmatic innovation. With brand-new design concepts, first-class quality, professional workmanship, we have a broad market and a good reputation! We constantly improve the relationship between banks and customers, master more customer information and improve customer satisfaction.

UL/CUL

Use Group B C D

Rate Voltage [V] 300 - 300

Rated Current [A] 12 - 10

Wire Range [AWG] 26~14

Dielectric Voltage-Withstand 1.6KV



IEC

Overvoltage Category III III II

Contamination Class 3 2 2

Rated Voltage [V] 250 400 630

Rated Current [A] 17.5 17.5 17.5

Impulse withstand voltage [KV] 4 4 4

Conductor cross section [mm²] 0.5~1.5



Material

Insulation Material PA66

Flammability rating UL94V-0

Conductor Material Copper alloy

Plating of conductor surface Sn plated



Other Data

Pitch/Poles [mm]/[P] 5.0/2~24

Stripping Length [mm] 5~6

Screw/Torque(Max)[N.m] M2.5/0.4

Operating temperature [℃] -40~+105

Soldering temperature 250℃/5S

Pin dimensions [mm] 0.6*0.9

PCB Hole Diameter [mm] Ø1.3



Looking back at the past, we focus on creating quality 128V-5.0mm-04p Black Screw Clamp Wiring Types Pluggable Terminal Block and serving customers wholeheartedly, which has led to remarkable achievements. Through independent research and development and industry-university-research cooperation, we continue to increase research and development of new products and new materials, and continuously improve product quality and product grades. While vigorously developing the economy, we always adhere to the development concept of "lucid waters and lush mountains are invaluable assets".
