M12 Male Straight Shield A-Coding 5PIN

Connector Series:M12

Gender: Male

Coding: A, B,C,D

Locking Type: Fix Screw

Mounting Type: Straight

Part No：M12-A05P-ST2-M02-BCC-100N

X:A Coding

**：05Pin

ST2:2=Full Shield

CC=Cable Jacket PVC(For Molded Cable)

CR=Cable Jacket PUR(For Molded Cable)

XXX:050=0.5M,100=1M,10M=10M...



Technical Data

Standard: IEC61076-2-101

Ambient Temperatur: -25℃~+80℃

Insulation Resistance :≥100MΩ

Contact Resistance :≤10mΩ

IP Class: IP67

Mating Endurance: >100 Mating Cycles



Material Data

Connector Carriers: PA

Connector Contacts: Copper Alloy With Gold Plated

Connector Nut/Screw: Copper Alloy With Nickel Plated

Shielding: Shielded

Connector Overmold: TPU



Electrical Data & Mechanical Date

Contacts Pin:5Pins

Rated Current: 4A

Voltage AC/DC: 60V / 60V

Wire Range AWG/mm²: 22 / 0.34
