M12 Male Front Fastened A-Coding 8PIN M12*1.0

Connector Series:M12

Gender: Male

Coding: A, B,C,D

Locking Type: Fix Screw

Mounting Type: Front Fastened

Part No：M12-A08P-ST0-M01-BQ3

X:A Coding

**：08Pin

BQ3=M12X1.0(OD3)



Technical Data

Standard: IEC61076-2-101

Ambient Temperatur: -25℃~+85℃

Insulation Resistance :≥100MΩ

Contact Resistance :≤10mΩ

IP Class: IP67

Mating Endurance: >100 Mating Cycles



Material Data

Connector Carriers: PA

Connector Contacts: Copper Alloy With Gold Plated

Connector Nut/Screw: Copper Alloy With Nickel Plated

Seal/O-Ring: FKM

Shielding: Unshielded

Length of the Solder Pin: 6mm



Electrical Data & Mechanical Date

Contacts Pin: 8Pins

Rated Current: 2A

Voltage AC/DC: 30V / 30V

Contacts Termination: PCB Version
